Chapter 9. The Quad External SAS Cable Feature
The Quad External SAS Cable (Feature Code 5544) allows the user to attach up to
four 7226 SAS Tape or DVD-RAM drives to just one system host bus adapter port.
This external cable option is recommended for IBM POWER System customers
who have a limited number of SAS host bus adapters available. It is 3 meters long.
7226 SAS drive features attach to an IBM POWER System SAS port using an
external SAS cable that is provided with each tape drive or DVD-RAM feature
ordered. Up to four 7226 SAS devices may be attached to a single SAS port using a
one-to-four Quad External SAS Cable (feature #5544). The four 7226 SAS devices
may be installed in more than one 7226 storage enclosure.
System x does not support 7226 attach through the Quad SAS Cable.
Note: If this feature is specified, the standard 3.0 meter SAS cable will still be
shipped with each SAS drive feature.
Feature Kit Contents
FC 5544 contains one Quad External SAS Cable.
Table 22. Feature Code 5544 Contents
Description Part Number Quantity
Quad External SAS Cable 46C2441 1
ROLSOS540-0
Figure 46. Contents of FC 5544
© Copyright IBM Corp. 2012 115
