Step 2. Checking the Electrical Outlets
Make sure that the electrical outlets you use are properly grounded.
DANGER
An electrical outlet that is not correctly wired could place hazardous voltage
on the metal parts of the system or the devices that attach to the system. It is
the responsibility of the customer to ensure that the outlet is correctly wired
and grounded to prevent an electrical shock. (D004)
Step 3. Assembling the Materials
Refer to your system management or system hardware manuals to locate the
information that you need to install the 7226 Storage Enclosure.
1. Get your system unit manuals now. You may find the needed information
under the topics:
v SAS controllers
v USB controllers
v Fibre Channel controllers
v External SAS devices
v External USB devices
v External Fibre Channel devices
2. Do not continue until you have verified where the SAS or USB controllers are
located (where you make the cable connection).
Record the controllers locations here
Step 4. Placing the 7226 Storage Enclosure
The 7226 Storage Enclosure should be installed in a system rack in a clean
environment. Consider the length of the power cord and the SAS, USB and Fibre
Channel cables and ensure that the media can be easily inserted when selecting the
location.
The 7226 Storage Enclosure should be installed at least 30 inches above the floor to
reduce contamination that can affect the drives.
To place the 7226 Storage Enclosure, do the following:
1. __ Mount the 7226 Storage Enclosure in the rack as described in Chapter 2,
“Installing the 7226 Storage Enclosure into a Rack,” on page 11.
2. __ Connect the power cable to the 7226 Storage Enclosure. (Do not plug it
into the electrical outlet at this time.) Route the power cable through the cable
management arm as described in Chapter 2, “Installing the 7226 Storage
Enclosure into a Rack,” on page 11.
Note: Heavy objects should not be stacked on the 7226 Storage Enclosure.
34 7226 Storage Device Enclosure Setup, Operator and Service Guide
