Table 4. Definition of Status Light Combinations (continued)
Activity Cleaning
(amber)
Media Fault
!
(amber)
Drive Fault
(amber)
Ready /Activity
(green)
Firmware
download
reprogram
failure
Off Off Flashing Off
SCSI diagnostics
test in progress
See Data cartridge loaded, activity
SCSI diagnostics
test passed
See Data cartridge loaded, no activity
SCSI diagnostics
test failed, tape
ejected
On On On Flashing
After data cartridge ejects, see Data cartridge ejected.
Tape diagnostics
test in progress
See Data cartridge loading and then:
Flashing Off Off Flashing
Tape diagnostics
test passed, tape
ejected
Off Off Off Flashing
After data cartridge ejects, see Data cartridge ejected.
Tape diagnostics
test failed, tape
ejected
On On On Flashing
After data cartridge ejects, see Data cartridge ejected.
Notes:
1. A solid amber Cleaning LED indicates that the drive needs cleaning. The drive will
continue to function but needs cleaning as soon as possible. Do not ignore the indicator
by cycling the power to turn it off.
2. The media has reached the end of its useful life and should be replaced. Any data
should be copied to a new cartridge as soon as possible.
3. Flashing in this state indicates a problem with write/read performance.
4. An unrecoverable drive failure is an error condition that results in the drive not being
able to function unless initiator, operator, or service intervention is applied. An
unrecoverable drive failure is usually the result of a hardware error condition. One of
the following actions is needed to clear the flashing fault LED:
v Hard SCSI reset
v Cartridge emergency eject
v Power cycle
v Retry firmware download
An unrecoverable media failure is usually the result of a defective cartridge, media, or
cartridge state, and will require the drive to eject the cartridge (if possible) to clear the On
LED.
50 7226 Storage Device Enclosure Setup, Operator and Service Guide
