12.3.2 Result type
With the "result type", the result type for the pixels of the ROI group is set. For each ROI group, one of the
following results can be set:
● [Min]
y
z
①
The figure on the left shows the result type "Min" with a 3D
grid made of ROIs. The result is marked with ①.
● [Max]
y
z
①
The figure on the left shows the result type "Max" with a 3D
grid made of ROIs. The result is marked with ①.
● [Mean value]
y
z
①
The figure on the left shows the result type "mean value"
with a 3D grid made of ROIs. The result is marked with ①.
● [Percentile]
y
z
①
The figure on the left shows the result type "Percentile"
with a 3D grid made of ROIs. P
1
= 90 % is marked with ①
(30 pixels).
y
z
②
The figure on the left shows the result type "Percentile"
with a 3D grid made of ROIs. P
2
= 50 % is marked with ②
(30 pixels).
