ifm Vision Assistant O3M
82
10.9.3 Example for increasing the number of valid pixels
In the following, you find an example of how the intelligent data averaging increases the number of valid
pixels.
Example Description
The device is oriented towards a car park
with cars.
The distances between the device and
cars are indicated by means of the
colours (→ „6 Monitoring window“):
● 1st row of cars in red
● 2nd row of cars in yellow
● 3rd row of cars in blue
Monitoring screen
The calculation of the average value is
switched off:
Monitoring screen
Calculation of the average value with low
sensitivity:
Result:
The number of valid pixels has increased.
