ifm Vision Assistant O3M
142
15.3 Description of the "Input" modules
In the "Input" selection area, available modules for entering signals are displayed.
The available modules depend on the installed firmware. Depending on the firmware variant (DI,
OD or LG) different input modules are available.
The following input modules are available in each firmware version:
Digital CAN input signals
Analogue CAN input signals
Extrinsic calibration
Diagnostics
15.3.1 "Digital CAN input signals" module
The "Digital CAN input signals" module can receive up to 14 binary input values (1 bit) dynamically across
the CAN interface.
The CAN interface is described in a separate CAN document.
The "Digital CAN input signals" module has the following setting:
Setting Data type Description
Index Binary Vector with 14 values, address range from 0-13
15.3.2 "Analogue CAN input signals" module
The "Analogue CAN input signals" module can receive up to 6 binary input values (12 bit) dynamically
across the CAN interface.
The CAN interface is described in a separate CAN document.
The "Analogue CAN input signals" module has the following setting:
Setting Data type Description
Index Numerical Vector with 6 values, address range from 0-5
