ifm Vision Assistant O3M
158
Module number Module Description
6 AND
If the measurement is valid and in the tolerance range of the reference value, a
"1" is output (area free).
If the measurement is invalid or not in the tolerance range of the reference
value, a "0" is output (area not free).
7 Digital output If a "1" is present at input "in1", a "1" is output at digital output "1".
Table of
input values:
ROI group
(index)
z-value
(height)
1 0.05 m
2 -0.02 m
3 0.25 m
4 -0.18 m
5 0.07 m
6 0.02 m
7 -0.09 m
8 0.16 m
Memory contents after
teach signal via CAN:
ROI group
(index)
Value
1 0.05 m
2 -0.02 m
3 0.25 m
4 -0.18 m
5 0.07 m
6 0.02 m
7 -0.09 m
8 0.16 m
Current
input values:
ROI group
(index)
z-value
(height)
Validity
1 -0.03 m 1
2 0 m 0
3 -0.11 m 1
4 -0.11 m 1
5 0.13 m 1
6 -0.02 m 1
7 0.07 m 1
8 0.18 m 1
Result of "Approx equal"
module:
Index
Calculated
value
Binary output
1 0.08 m 1
2 0.02 m 1
3 0.36 m 0
4 0.07 m 1
5 0.06 m 1
6 0.04 m 1
7 0.16 m 1
8 0.02 m 1
Logic output (after "AND" module
with valid values):
Index Digital output
1 1
2 0
3 0
4 1
5 1
6 1
7 1
8 1
