Invacare LiNX - Port Pin-Outs; Actuator Port Configurations (Factory Setup)

Assembly
RearWheelDriveCenterWheelDrive
Fox
Kite,KiteHD
Storm
4
,Storm
4
X-plore,
Storm
4
Max
1
Stream
1
1
noDLX-ACT200/400onStorm
4
MaxandStream
3.6Portpin-outs
DLX-PM60,DLX-PM75,DLX-PM120
A
LiNXcommunicationbus
B
Motor/parkbrakeportM1
C
Batteryport
D
Motor/parkbrakeportM2
E
Utilityport
DLX-PM60AL,DLX-PM75AL,DLX-PM120AL
A
LiNXcommunicationbus
B
Motor/parkbrakeportM1
C
Batteryport
D
Motor/parkbrakeportM2
E
Actuatorports
F
Lightingport
G
Utilityport
3.7ActuatorPortCongurations
(FactorySetup)
Actuatorports,propertiesandbehaviorperactuatorare
denedbyInvacare.Youcanchangespeed,directionand
operationmode.Thisisdoneindifferentmenus,referto
8.7ModifyingSeatingParameters,page90.
SeatingMotion
Theseatingmovementiscalledseatingmotion.The
seatingmotiondenestheicondisplayedontheuser
interface,overallspeed,theindividualactuatorsand
theirspeeds.Aseatingmotioncancontroloneormore
actuators.Therearesixseatingmotionsdenedinthe
factoryset-up.
SeatingFunction
Theseatingfunctionistheuserinputanddeneshow
themotionisoperated.
1605129-G13
