The“AL”powermodulesthatfeatureactuatorsand
lights,havetwoactuatorports.Ifrequired,thesystemis
completedwiththeDLX-ACT200orDLX-ACT400,basedon
theconguration.Thefollowingchaptersdetailtheport
set-uppermodule/conguration.
3.7.1PortcongurationsforsystemswithDLX-REM2xx(EU-VersionwithModuliteseat)
Channel
Seatingmotion(Icon)Seatingfunction(Operation)
A
Tilt
ProportionalFWD/REV
B
Recline
ProportionalFWD/REV
C
Rightleg
ProportionalFWD/REV
D
Leftleg/
Center-mounted
legrest
Bothlegs
ProportionalFWD/REV
E
Lifter
ProportionalFWD/REV
Portcongurationwithoutlifter
Powermodule
DLX-ACT200
DLX-ACT400
