Invacare®LiNX
Drivestatistic
Details
DriveTime
Thetotaltimethatthe
wheelchairhasbeendriven.
AverageDriveTime
Averagedrivetime.
TimeNearMaximum
Current
Thedurationthecurrent
waswithin20%ofmaximum
threshold.
TripDistance
Thetotaldistancetravelledby
thiswheelchairinmeterssince
beingresetbytheuser.
TotalDistanceTravelledThetotaldistancetravelledby
thiswheelchairsincebeingreset
byaprovider .
DriveStatisticsLast
Reset
Datewhenthesestatisticswere
lastreset.
ResettingDriveStatistics
1.
iOStoolPCtool
Fig.11-7
Fig.11-8
ClickonResetDriveStatisticsbutton.
2.
iOStoolPCtool
Fig.11-9
Fig.11-10
ClickonOKorYestocontinue.
ClickonBackorClosebuttontoexittheChairStatistics
11.4ViewingLiveDiagnostics
Fig.11-11
TheLiveDiagnosticsareonlyavailablewhentheLiNX
AccessiOStoolisconnectedtoawheelchair.The
parameters(seeParameterlist,page144 )ontheLive
Diagnosticsscreenaresplitintotwocategories:
•Drive,and
•Actuators.
Parameterlist
Drive
SpeedDemand(%)
TurnDemand(%)
LeftMotor
•Voltage(V)
•Current(A)
•Resistance(mΩ)
RightMotor
•Voltage(V)
•Current(A)
•Resistance(mΩ)
BatteryVoltage(V)
SpeedDial(%)
Actuators
SensorAngle(°)
1.ClickLiveDiagnosticsbutton.
2.Clickdesiredcategorytoviewreal-timegraphsand
data.
3.ClickBackbuttontwicetoexitLiveDiagnostics.
11.5Clearingtheeventlog
Thisfeatureisonlyavailablewhenawheelchairisin
Connectioncontextmode.
PCtool
Tocleartheeventlog,clickontheResetLogbuttonatthe
topofthelogs.
144
1605129-G
