Invacare®LiNX
Dependingonconguration,theEggswitchASL300canbeconnectedtotheprimaryremote.
Conguration
wtilt,wrecline,w/o
lifter
wtilt,w/orecline,
w/olifter
wtilt,wrecline,w
lifter
wtilt,w/orecline,w
lifter
A
1200mm1200mm1500mm1500mm
B
1
REM400:1500mm
REM500:1700mm
REM400:1500mm
REM500:1700mm
REM400:1500mm
REM500:1700mm
REM400:1500mm
REM500:1700mm
C
700mm1200mm700mm1200mm
D
300mm300mm300mm300mm
E
2
1700mm1200mm1200mm1200mm
F
300mm300mm300mm300mm
G
300mm300mm300mm300mm
H
300mm300mm300mm300mm
I
300mm300mm300mm300mm
J
300mm300mm300mm300mm
K
300mm300mm300mm300mm
1
Dependingonprimaryremote
2
BusporteitherforDLX-CR400orforRemoteStopSwitch.Cannotbecombined.
3.9Mountingtheprimaryremotes
Formoreinformationabouthowremoteholders
aremountedtothewheelchair,refertotheservice
manualoftheseatingsystem.
3.9.1MountingDLX-REM1XXandDLX-REM2XX
forModulite
StandardRemoteHolder
•3mmAllenkey
•8mmwrench
1.
MountjoystickholderAtoremoteadapterBwith
screwsC,washersDandnutsE.
2.
MountremoteHtoremoteadapterBwithscrews
FandwashersG.
Swing-AwayRemoteHolder
•4mmAllenkey
•3mmAllenkey
•8mmwrench
•10mmwrench
321605129-G
