Invacare®LiNX
3.8.3WiringforModuliteSeatingSystem(FoxOnly)
WiringforFoxwithModulite:DriveOnlywithACU
Fig.3-6
Cablelengthmayvarydependingonmountingpositionsofprimaryandsecondaryremotesandof4–wayconnector
GLM-CONX4.
A
300mm+640mmextensionloom
B
1000mm
C
1000mm
261605129-G
