Invacare®LiNX
3.12.2MountingtheCompactSingleSwitch
Joystick
LateralTrayMount
•1/8inchAllenkey
•5/32inchAllenkey
•3/16inchAllenkey
1.
Fig.3-61
InsertjoystickOinclampN,pullclampoveradapter
blockKandxwithscrewsL.
2.
Fig.3-62
InsertclampplateBintocutoutontrayA.
3.FixclampplateB,clampballCandupperclamp
plateDwithscrewsE.
4.
Fig.3-63
MountanglebracketFwithscrewsGtotrayA.
5.
Fig.3-64
InsertremoteOintotrayA.
6.FixadapterblockKtoanglebracketFwithscrewH
andwasherI.
NucleusTrayMount
CAUTION!
RiskofInjuryandDamage
Remainingburrsandmissingendcapsafter
modicationsonrods,suchasshortenedrod,
canleadtoinjuryordamage.
–Deburrcutaftercuttingexcessivelength.
–Re-installendcapafterdeburring.
–Checkendcapfortighttting.
•1/8inchAllenkey
•5/32inchAllenkey
•3/16inchAllenkey
461605129-G
