Assembly
MountingASL106InterfaceBoxforUltraLowMaxx
(PoweredRecline)
•1/8inchAllenkey
•5mmAllenkey
•6mmAllenkey
•13mmwrench
1.
Fig.3-55
LoosenandremovenutC,washers,spacersand
boltA.
2.Re-insertboltAandangeB,washers,spacersand
nutC.
3.Tightennut.
4.
Fig.3-56
InsertboltsD.
5.InstallholderH,washersEandnutsF.
6.TightennutsF.
7.InstallendcapsG.
8.
Fig.3-57
TighteninterfaceboxJtoholderHwithscrewsI.
MountingASL106InterfaceBoxforModulite
•1/8inchAllenkey
•5mmAllenkey
•13mmwrench
Fig.3-58
1.InsertboltsD.
2.InstallholderH,washersEandnutsF.
3.TightennutsF.
4.
Fig.3-59
TighteninterfaceboxJtoholderHwithscrewsI.
MountingASL154SipAndPuffInterfaceBoxforUltra
LowMaxx
•5mmAllenkey
•Flatscrewdriver
Fig.3-60
1.LoosenscrewA.
2.PlaceholderonarmresttubeEandre-tighten
screwA.
3.InstallInterfaceBoxCandtightenscrewsD.
1605129-G45
