Invacare®LiNX
ensurethattheconnectorsBfacingdownwards,sothat
theconnectorrecesseswillnotcollectorretainforeign
matterorliquids.
Incorrectmounting
A
Rear
B
Connectors
C
Top
D
Base
Testing
TheLiNXsystemmustbefullytestedafterallmodulesand
cableshavebeeninstalled.
3.5Mountingpositionsonwheelchairs
ThepositionsofthepowermodulesAandDLX-ACT200/400Bdependingonwheelchairmodeland—conguration
areshowninthetablebelow.Forfurtherinformationaboutaccesstothecomponents,refertotheService
manualoftheparticularwheelchairmodel.
RearWheelDriveCenterWheelDrive
AVIVARXwithModuliteseat
ProntoM41,TDXSP2,TDX
SP2narrowbase,TDXSP2
widebasewithModulite
seat
AVIVARXwithUltraLow
Maxxseat
TDXSP2narrowbaseand
TDXSP2widebasewith
UltraLowMaxxseat
Bora/SpectraXTR,Spectra
XTRHDw/olifter/tiltmodule
Bora/SpectraXTR,Spectra
XTRHDwlifter/tiltmodule
12
1605129-G
