Invacare LiNX - Wiring for Modulite Seating System

Invacare®LiNX
3.8.1WiringforModuliteSeatingSystem
WiringforModulite:Lifter,Tilt,Recline,PoweredElevatingLegrests,Lights,DualControl,SecondaryInput,DLX-ACT400,
GLM-CONX4(2x),DLX-IN200andUSBCharger
Fig.3-1
Cablelengthmayvarydependingonmountingpositionsofprimaryandsecondaryremotesandof4–wayconnector
GLM-CONX4.
Model
A A
A
B B
B
C C
C
D D
D
E E
E
Kite
2500mm1500mm300mm700mm700mm
SpectraXTR
2
HD,
Bora/SpectraXTRStandard
1700mm1700mm300mm700mm700mm
TDXSP21500mm1200mm300mm300mm700mm
Storm
4
,
Storm
4
X-plore
1500mm1200mm300mm500mm300mm
AVIVARX1500mm1500mm300mm300mm700mm
181605129-G
