3.9.3MountingtheDLX-REM400
StandardRemoteHolder
•3mmAllenkey
•8mmwrench
1.
Fig.3-22
MountjoystickholderAtoremoteadapterBwith
screwsC,washersDandnutsE.
2.
Fig.3-23
MountremoteHtoremoteadapterBwithscrews
FandwashersG.
Swing-AwayRemoteHolder
•4mmAllenkey
•3mmAllenkey
•8mmwrench
•10mmwrench
Fig.3-24
1.PullscrewsDthroughbracketC,remoteholderand
washersB.
2.TightenscrewswithnutsA.
3.PullscrewsFthroughwashersE,bracketCand
bracketGandtightenscrews.
4.
Fig.3-25
TightenremotewithscrewsAtobracketG.
QuadLinkRemoteHolder
•3mmAllenkey
•5mmAllenkey
Fig.3-26
1.MountLiNXremoteadapterBwithscrewsAto
remoteC.
TheLiNXremoteadaptercanbeturned90°
rightorleftformoreadjustmentoptions.
2.MountremotetoQuadLinkFwithscrewD,
Nord-LockwasherEandserratedlockwasherG.
TightenscrewDwithamaximumtorqueof
25Nm.
RemoteHolderforAttendantonPoweredBackrest
Theremoteisttedtothewheelchairusingabracketon
thepushhandleorthepushbar .
