Assembly
1.
Fig.3-16
MountremoteAwithsupportBandsupportdrum
CtoclampDwithscrewsFandwashersE.
2.
Riskofdamagetotheremote
Themaximumtorquetotightenthescrew
is1Nm.
–Donotexceedthisratingasitmay
damagetheremote.
FixsupportdrumCinclampDwithscrewG,washer
HandnutI.
3.
Fig.3-17
AttachclampDtobracketJwithscrewsLand
washersK.
4.
Fig.3-18
AttachbracketJtogripperclampMwithscrewsN
andnutsO.
RemoteHolderforAttendantonManualBackrest
Theremoteisttedtothewheelchairusingabracketon
thepushhandleorthepushbar .
•4mmAllenkey
•5mmAllenkey
•8mmwrench
•Threadlockingadhesive(Loctite225orsimilar)
1.
Fig.3-19
MountremoteAwithsupportBandsupportdrum
CtoclampDwithscrewsFandwashersE.
2.
Riskofdamagetotheremote
Themaximumtorquetotightenthescrew
is1Nm.
–Donotexceedthisratingasitmay
damagetheremote.
FixsupportdrumCinclampDwithscrewG,washer
HandnutI.
3.
Fig.3-20
InstallgripperclampKtopushbarusingscrewsL
andnutsJ.
Tightenscrewswith10Nm.
4.
Fig.3-21
InsertscrewsNthroughgripperclampJandspacers
MinclampD.
Usethreadlockingadhesiveandtightenscrewswith
10Nm.
NucleusMidlineHolder
Formountingprimaryremotestonucleusmidlineholder,
referto3.10MountingPrimaryRemotestoNucleus
MidlineHolder,page39.
