Assembly
•4mmAllenkey
•8mmwrench
1.
Fig.3-27
MountremoteAwithsupportBandsupportdrum
CtoclampDwithscrewsFandwashersE.
2.
Riskofdamagetotheremote
Themaximumtorquetotightenthescrew
is1Nm.
–Donotexceedthisratingasitmay
damagetheremote.
FixsupportdrumCinclampDwithscrewG,washer
HandnutI.
3.
Fig.3-28
AttachclampDtobracketJwithscrewsLand
washersK.
4.
Fig.3-29
AttachbracketJtogripperclampMwithscrewsN
andnutsO.
RemoteHolderforAttendantonManualBackrest
Theremoteisttedtothewheelchairusingabracketon
thepushhandleorthepushbar .
•4mmAllenkey
•5mmAllenkey
•8mmwrench
•Threadlockingadhesive(Loctite225orsimilar)
1.
Fig.3-30
MountremoteAwithsupportBandsupportdrum
CtoclampDwithscrewsFandwashersE.
2.
Riskofdamagetotheremote
Themaximumtorquetotightenthescrew
is1Nm.
–Donotexceedthisratingasitmay
damagetheremote.
FixsupportdrumCinclampDwithscrewG,washer
HandnutI.
1605129-G37
