Aircraft Technical Manual
J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
5. Inspect bolt seats in fuselage for signs of damage, wear or perishing.
6. For the leg shown in Figure 71, inspect the outboard clamp flock bed & re-flock if damaged.
WARNING
Repairs to the composite undercarriage beams must be referred to JABIRU AIRCRAFT Pty Ltd or
our local approved agent.
6.34 Trouble Shooting – Main Undercarriage (all J-Series)
Table 0-1 – Trouble Shooting – Main Undercarriage
Aircraft leans to one side
Inflate to pressure shown at
above
Landing gear attaching parts not
tight
Tighten loose parts. Replace
defective parts.
Inflate to pressure shown in
above
Main wheels out of alignment
Figure 71 – Main Undercarriage (Type 1)
