Aircraft Technical Manual

Jabiru Aircraft Pty Ltd

JTM001-5

J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants

This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.

ISSUE

Dated: 29th October 2014

Issued By: AS

Page: 293 of 298

Control horns, hinges, hinge lock tabs – check condition and wear, replace as required

Rigging check flight – Check all system for correct function

Throttle controls – Check smooth operation and correct adjustment of friction

Check control surface clearances – as per section 5.18

Comments:

hourly

Comments:

Annual

Comments:

Annual

Comments:

Annual
