6.73 Rudder (all J-Series)
6.73.1 Description
The rudder of Jabiru Aircraft is a stressed-skin composite structure. It is connected to the rudder
pedals via a self-contained push-pull cable.
6.73.2 Removal & Installation
Spanners / Socket Wrench
Screwdrivers
L1, L2 or LAME (Owner, A&P or LSA Repairman / Maintenance)
L1, L2 or LAME (Owner, A&P or LSA Repairman / Maintenance)
1. Unbolt push-pull cable from rudder horn.
2. Loosen screws in hinge pin retainers & lift retainer from hinge pin. It is not necessary to remove
these parts.
3. Remove hinge pins.
4. Remove rudder.
5. Reverse the preceding steps for installation.
6.73.3 Inspection & Repair
L1, L2 or LAME (Owner, A&P or LSA Repairman / Maintenance)
L1, L2 or LAME (Owner, A&P or LSA Repairman / Maintenance)
Inspect rudder for any signs of delamination or cracking. Pay particular attention to the Control Horn
and hinges and their surrounding areas.
Inspect the front right-hand of the rudder for any signs of rubbing against the vertical stabiliser when
the rudder is at full deflection: when the rudder hinge is pressed in using thumb pressure there
should be clearance between the rudder and the vertical stabiliser.
Details of inspections required for control surfaces are given in Section 5.18.
Repairs must be referred to Jabiru Aircraft Pty Ltd or our approved local agent.
