Jabiru j430 - Figure 16 - Weighing Diagram

To Next Page

To Previous Page

Aircraft Technical Manual

Jabiru Aircraft Pty Ltd

JTM001-5

J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants

This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.

ISSUE

Dated: 29th October 2014

Issued By: AS

Page: 56 of 298

NOTE: The CG datum point for the J120-C is an imaginary line 1403mm forward of the right wing

leading edge. Most CG calculations must be carried out relative to this datum.

Figure 16 – Weighing Diagram.
