Jabiru Aircraft Pty Ltd
CASA APPROVED SECTION
Airworthiness Limitations
Jabiru J160-C
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
ISSUE
1
2
3
4
Dated: 29th October 2014
Issued By: AS
Page: 298 of 298
Table 22-1 – Control Surface Balancing Limits
Control
Hinge Moment Limits
Weight Limits
Manual Section
Rudder
17500g.mm
+/- 4000g.mm
2100g
+/- 100g
6.75 Rudder Balance
Aileron
94000g.mm
+/- 4000g.mm
1150g
+/- 100g
6.53.4 Aileron Balancing
Elevator
259000g.mm
+/- 4000g.mm
4600g
+/- 100g
6.65.3 Elevator Balancing
22.5 Mandatory Inspections and Replacements
Table 22-2 – Mandatory Inspection Times
Description
Part No.
Interval
Rudder Cable
#
PC01404
1000 hours
Elevator Cable
#
PC3A001
1000 hours
Aileron Cable (2)
#
PC01614
1000 hours
Overall Condition*
Entire Airframe
5000 hours
22.5.1 Mandatory Replacement
 The following components MUST be replaced at the intervals described hereunder.
Table 22-3 – Mandatory Replacement Times
Description
Part No.
Interval
Rudder Cable
PC01404
10 000 hours
Elevator Cable
PC3A001
10 000 hours
Aileron Cable (both)
PC01614
10 000 hours
Undercarriage bolts and nuts (all)*
Various
500 hours
Engine bay Flexible hoses (all)*
Various
2 years**
#
see Section 5.17.
* see Section 5.3 Mandatory Inspections & Lifed Items
** 2 years or at engine overhaul, whichever comes first
