Jabiru j430 - Identification Stampings

Aircraft Technical Manual
Jabiru Aircraft Pty Ltd
JTM001-5
J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
ISSUE
1
2
3
4
5
Dated: 29th October 2014
Issued By: AS
Page: 237 of 298
Table 9-2 – Approved Scimitar Propeller Installations (Factory built Models)
Propeller
Airframe
Engine
Propeller
Flange
Dia x Pitch
Specification
Limits
4A482U0D
Jabiru J120-
C
Jabiru 2200
4662084 Family
1524 x 965
(60” x 38”)
Not Above 3300
RPM
4A482U0D
Jabiru J160-
D
Jabiru 2200
4662084 Family
1524 x 965
(60” x 38”)
Not Above 3300
RPM
4A482U0D
Jabiru J170-
C
Jabiru 2200
4662084 Family
1524 x 965
(60” x 38”)
Not Above 3300
RPM
4A482U0D
Jabiru J170-
D
Jabiru 2200
4662084 Family
1524 x 965
(60” x 38”)
Not Above 3300
RPM
4A484E0D
Jabiru J230-
C
Jabiru 3300
4662084 Family
1524 x 1321
(60” x 52”)
Not Above 3300
RPM
4A484E0D
Jabiru J230-
D
Jabiru 3300
4662084 Family
1524 x 1321
(60” x 52”)
Not Above 3300
RPM
Table 9-3 – Approved Scimitar Propeller Installations (Kit built Models)
Propeller
Airframe
Engine
Propeller
Flange
Dia x Pitch
Recommendation
Limits
4A482U0D
Jabiru J120
Family
Jabiru
2200
4662084 Family
1524 x 965
(60” x 38”)
Not Above
3300 RPM
4A482U0D
Jabiru J160
Family
Jabiru
2200
4662084 Family
1524 x 965
(60” x 38”)
Not Above
3300 RPM
4A482U0D
Jabiru J170
Family
Jabiru
2200
4662084 Family
1524 x 965
(60” x 38”)
Not Above
3300 RPM
4A484E0D
Jabiru J230
& J430
Family
Jabiru
3300
4662084 Family
1524 x 1321
(60” x 52”)
Not Above
3300 RPM
4A484E0D
Jabiru J200
& J400
Family
Jabiru
3300
4662084 Family
1524 x 1321
(60” x 52”)
Not Above
3300 RPM
4A484E0D
Jabiru J250
& J450
Family
Jabiru
3300
4662084 Family
1524 x 1321
(60” x 52”)
Not Above
3300 RPM
9.3 Identification Stampings
 Each Jabiru propeller is marked with the particulars indicated below:
1. The Propeller Drawing Number.
2. The diameter and pitches in metres, preceded by the letters "D" and "P" respectively.
3. The type of engine for which the propeller has been designed.
4. Manufacturing Serial Number:
