9 Propeller Service Manual
9.1 Certified Propeller Models (J160-C)
C000242 series propellers with a serial number of 2900 or higher and 4A401 series propellers with a
serial number of 002 must be maintained in accordance with Propeller Technical Manual JPM3L01.
The information given below is not applicable to these propellers.
Operators with earlier propellers may also use manual JPM3L01 for reference, but must be aware
that there may be differences between the propellers detailed in the manual and their own.
Operators using the composite scimitar propellers (4A482U0D or 4A484E0D) must maintain their
propeller in accordance with the propeller technical manual JPM0001.
9.2 Approved Installations (all J-Series)
The following combinations (Table 9-1, Table 9-2, Table 9-3) are approved.
Table 9-1 – Approved Propeller Installations
Jabiru J160-D,
J170-C, J170-D
Sensenich 2-
bladed Fixed
pitch wooden.
1524 x 1092
(60” x 43”) or
1524 x 1168
(60” x 46”)
Other Jabiru J160
& J170 Variants.
J120-C
1524 x 1117
(60” x 44”) or
1524 x 1067
(60” x 42”)
J200, J230, J250 &
Variants, including
J230-C, J230-D
1524 x 1346
(60” x 53”) or
1524 x 1397
(60” x 55”)
Sensenich 2-
bladed Fixed
pitch wooden.
1524 x 1346
(60” x 53”) or
1524 x 1397
(60” x 55”) or
1524 x 1422
(60” x 56”)
