5.4 Inspection Chart
 The Engine Maintenance Manual also details engine inspection schedules and should be consulted
in addition to this chart.
 The chart below shows the recommended intervals at which items are to be inspected.
 Additional detail of the maintenance required in each section is given in the sections below the
inspection chart.
 As shown in the chart, there are items to be inspected each 100 hours, each 200 hours and
Annually. There are also special inspection items that require inspection or servicing at intervals
other than 100, 200 hours or Annually.
 When conducting an inspection at 100 hours, all items marked under Each 100 Hours is inspected,
serviced or otherwise completed.
 At each 200 hours inspection, the 100 hours items are completed in addition to the items marked
under Each 200 Hours.
 An inspection conducted Annually would likewise include the 100 hour items and 200 hour items in
addition to the items marked under Annual Inspection.
 A complete aircraft inspection includes all 100, 200 hour and Annual items together with those
shown in the Engine Maintenance Manual and Propeller Manual.
 Special Inspection items are carried out as required or as specified in Table 5-1 below.
Table 5-1 – Inspection Chart
Annual Inspection
Each 200 Hours
Each 100 Hours
PROPELLER
1
Spinner
*
*
*
2
Spinner Flange
*
*
*
3
Spinner screws
*
*
*
4
Propeller
*
*
*
5
Propeller bolts/nuts - Tension
*
*
*
6
Spinner / Prop Tracking
*
*
*
ENGINE COMPARTMENT
Note: refer to engine maintenance manual for engine-
specific inspections.
1
Carburettor air filter
*
*
*
2
Engine baffles and air ducts
*
*
*
3
Oil Hoses, lines, fire-sleeve & fittings
*
*
*
4
Fuel Hoses, lines, fire-sleeve & fittings
*
*
*
