Jabiru j430 - Figure 105 - Linear Actuator Disassembled

To Next Page

To Previous Page

Aircraft Technical Manual

Jabiru Aircraft Pty Ltd

JTM001-5

J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants

This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.

ISSUE

Dated: 29th October 2014

Issued By: AS

Page: 158 of 298

Figure 105 – Linear Actuator Disassembled (all J-Series)

Figure 106 – Commutator Ring Close-Up (all J-Series)

Remove screws

to allow cover to

be removed for

motor access.

Commutator Ring

Commutator Ring.

Black material

must be removed.

Gaps between segments

of the ring must be

cleaned.
