11.7.2 Removal & Installation
Required Tools:
Tools as required in Section 11.2.2
Screwdrivers
Parts and Material:
N/A
Type of Maintenance:
Line Maintenance
Level of Certification:
L2 or LAME (A&P or LSA Repairman / Maintenance)
Return to Service:
L2 or LAME (A&P or LSA Repairman / Maintenance)
 Remove the instrument panel fascia as detailed above.
 Disconnect the instrument.
 Undo the fasteners and remove the instrument from the fascia.
 For installation, reverse removal steps above.
Table 11-5 – Trouble Shooting – Tachometer
Trouble
Probable Cause
Remedy
Instrument fails to
operate
Circuit breaker open
Check master and avionics
circuit breakers. Re-set if
necessary.
Defective mechanism
Substitute known-good
tachometer and check reading.
Replace instrument
Incorrect indication
Sensor not positioned correctly
Adjust sensor per Engine Manual
Instructions.
Analogue Tacho: Incorrectly set
dip-switches or tachometer
programming.
Check switch positions /
programming as appropriate to
the tachometer. Refer to engine
manuals.
Hand oscillates
Same probable causes as for
“Incorrect Indication” above.
See remedies for “incorrect
indication” above.
