6.6.4 Door Seals
 A weather strip is glued around all edges of the door. Apart from excluding wind and water, the
weather strip is important in minimising exhaust fume entry to the cabin. It should be maintained in
good condition and fit at all times. New weather strip may be applied after mating surfaces of
weather strip and door are clean, dry and free from oil and grease.
6.7 J200-Type Cabin Door Latches (J200/J400)
6.7.1 Description
 There is one main latch on each door of a simple spring type. This is complemented by a catch at
the top front quadrant of each door. An assembly drawing of the latch mechanism is provided as
Figure 47 below.
6.7.2 Removal And Installation
 Disassembly and removal of the main latch requires cutting or drilling into the door skins to allow the
removal of the locking pins.
6.7.3 Adjustment
 Door latches or their component parts must be replaced if worn or damaged.
Figure 44 – J200-Type Door Hinge Assy (J200/J400)
