Jabiru j430 - Choke Cable

Aircraft Technical Manual
Jabiru Aircraft Pty Ltd
JTM001-5
J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
ISSUE
1
2
3
4
5
Dated: 29th October 2014
Issued By: AS
Page: 207 of 298
7.8 Choke CABLE (all J-Series)
7.8.1 Description
 The Choke Control is normally located in the main instrument panel & is connected to the
carburettor by a control cable. In some cases the Choke Control may be located on the left-hand
side of the firewall beside the instrument panel.
7.8.2 Removal, Inspection & Installation
Required Tools:
Fine nose pliers
Screwdrivers
Soldering iron or gas burner (for older aircraft only)
Parts and Material:
Fireproof putty
Type of Maintenance:
Line Maintenance
Level of Certification:
L1, L2 or LAME (Owner, A&P or LSA Repairman / Maintenance)
Return to Service:
L1, L2 or LAME (Owner, A&P or LSA Repairman / Maintenance)
 Disconnect the choke inner & outer cable from the carburettor.
 To remove the cable end fitting, remove the cotter pin (Figure 150). Note that for older aircraft
the soldered end fitting must be heated (with a powerful soldering iron or small gas burner) and
removed when the solder melts.
 Undo the clamp nuts from the cabin end of the cable.
 Where equipped, un-screw and remove the fireproof fitting on the firewall which the cable passes
through.
 Draw the cable through the firewall & panel. In some cases removal of the end fitting will be
necessary to achieve this.
 Installation is the reverse of the removal process above. Note that when the firewall fitting is re-
fitted fireproof putty (available from Jabiru Aircraft) must be replaced to ensure a flame-proof
seal.
