Jabiru j430 - Figure 15 - Undercarriage

To Next Page

To Previous Page

Aircraft Technical Manual

Jabiru Aircraft Pty Ltd

JTM001-5

J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants

This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.

ISSUE

Dated: 29th October 2014

Issued By: AS

Page: 43 of 298

5.3.4 Undercarriage

 Main undercarriage bolts and nose leg pivot bolts shown in Figure 15 are to be changed every 500

hours TIS.

Figure 15 – Undercarriage (all J-Series)

7 Bolts & nuts in total to be replaced.
