Aircraft Technical Manual

Jabiru Aircraft Pty Ltd

JTM001-5

J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants

This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.

ISSUE

Dated: 29th October 2014

Issued By: AS

Page: 148 of 298

Figure 94 – Clamp Comparison & Installation (Rudder Cable) (all J-Series)

Figure 95 – Clamp Installations (Elevator & Aileron) (all J-Series)

Figure 96 – Trim Cable Clamp Installation (all J-Series)

Primary Control Cable Clamp

(note square corner of clamp)

Rudder cable clamp properly installed.

Note seal pulled back slightly

Elevator cable clamp properly installed.

Aileron cable clamp properly installed

(viewed through inspection window).

Trim Cable Clamp

(note that it is larger

than primary control

cable clamp)
