Aircraft Technical Manual
Jabiru Aircraft Pty Ltd
JTM001-5
J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
ISSUE
1
2
3
4
5
Dated: 29th October 2014
Issued By: AS
Page: 185 of 298
6.71.2 Removal and Installation
Required Tools:
Spanners / Socket Wrench
Parts and Material:
N/A
Type of Maintenance:
Line Maintenance
Level of Certification:
L1, L2 or LAME (Owner, A&P or LSA Repairman / Maintenance)
Return to Service:
L1, L2 or LAME (Owner, A&P or LSA Repairman / Maintenance)
1. Unbolt push-pull cable.
2. Disconnect centring springs
3. Unbolt both steering push rods.
4. Unbolt rudder pedal bearings.
5. Remove cover plates and nylon bearings.
6. Remove both pedal bars.
7. Reverse the preceding steps for installation.
6.71.3 Inspection and Repair
Required Tools:
Spanners / Socket Wrench
Parts and Material:
Replacement parts (if required)
Type of Maintenance:
Line Maintenance
Level of Certification:
L1, L2 or LAME (Owner, A&P or LSA Repairman / Maintenance)
Return to Service:
L1, L2 or LAME (Owner, A&P or LSA Repairman / Maintenance)
1. Inspect nylon bearings for wear. Replace if worn.
2. Inspect pedal bars for wear around bearing area and for distortion.
3. Inspect pedals for distortion or loose rivets in end stops.
4. Inspect bolt holes for wear and elongation.
5. Inspect cable attachment lug, making sure it is not bent or distorted
6. Inspect bolts and nuts for distortion and wear.
7. Replace any distorted or worn parts.
 If the optional adjustable rudder pedals are fitted these steps must also be performed:
8. Inspect adjustment pins for wear, replace if required.
9. Inspect adjustment pin springs and replace if required.
10. Inspect adjustment pin pull rings for wear, replace if required.
WARNING
All spherical rod end bearings must be fitted with a large washer on the outside of the
through-bolt to prevent the bearing case and cable releasing in the event of a bearing failure.
