Fitted to the outside of RH Door Above the Door Catch Level
Door String Placard
P/No5026094
Fitted on Inside of both Doors Above Door Handle.
Loading Limitations
P/No 5A037A0D.
Fit to right side of fuselage between window and beam.
No Smoking
P/No. 5A035A0D
Fit to instrument panel.
Fuel Contents
P/No. 5A022A0D
Where Equipped
Fitted to sight glasses of wing fuel tanks.
Fuel Contents
P/No. 5A053A0D
Where Equipped
Fitted around the fuel gauge opening to the wing fuel tanks
Fuel Contents
5A050A0D
Where Equipped
Fitted beside fuel gauges in instrument panel
Fuel Tap Position
P/No 502319N
Where Equipped
Fitted on the Main Beam in front of the Fuel SELECTOR Valve
Fuel Tap Position
P/No 502329N
Where Equipped
Fitted on the rear of the fuselage beam next to the wing tank valves
PULL TO OPEN
J400 DECAL #1 - P/No. 502319N
J400 DECAL #2 - P/No. 502329N
