Aircraft Technical Manual
J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
21.1.4 Landing Gear (refer to section 5.11)
CARRIED OUT BY (print name)....................................(signature)................................(date)............
Shockwave indicator tripped (if fitted)
Main gear wheels & fairings – Remove fairings, inspect fairings and wheels for damage
Nose gear wheel, steering links, tension links and fairings - Inspect for damage
Wheel bearings – Check for smooth rotation
Nose gear strut – Check for rubbing, cracks missing hardware etc
Nose gear housing & bushes – Inspect for sign of wear
Main gear legs, clamps, bolts & nuts – Check for rubbing, cracks, corrosion, missing hardware
Main gear bolts – Replace as specified by intervals in section 5.3
Tyres and tubes – Check pressure, examine for wear, cuts, bruises and slippage
Brake fluid, hoses, linings, discs, brake assemblies & master cylinder(s)
Rod ends – Check condition, freedom of movement
