2-2 4222983 Second Edition
SPECIFICATIONS AND GENERAL INFORMATION
2
Machine Identification
Machine Serial Number
See Figures 2-1 and 2-2.
Figure 2-1
Figure 2-2
A machine identification plate (1) listing the serial number
(3) and a label (2) indicating the machine weight are
attached to the rear frame of the mower near the steering
yoke. Always provide the serial number of the machine
when ordering replacement parts or requesting service
information.
Engine Serial Number—Model 62805
(Diesel)
See Figure 2-3.
Figure 2-3
The engine serial number (1) is attached to the top of the
rocker arm cover. The plate also includes the engine
model number and the engine code number. An engine
data tag (2) attached to the top of the rocker arm cover.
The tag includes information on valve adjustment
specifications, injector timing, engine idle speed, and
engine displacement.
TN2745
1
®
P. O . B O X 7 7 0 8 ,
CHARLOTTE,
NC 28241, USA
A Textron Company
kg kg kg kW
Jacobsen.com
1-800-848-1636 (US)
TN2129,TN2735
2
3
TN2435
1 2
