4-8 4222983 Second Edition
ELECTRICAL
4
Main Harness Splice Identification and Locations
See Figure 4-4.
Figure 4-4: Main Harness Splice Identification and Location
1 Splice A 5 Splice H
2 Splice B 6 Splice O
3 Splice C 7 Splice T
4 Splice E 8 Reel Motor Harness Splice
TN3373
1
2
3
7
5
4
6
8
8
8
