CHASSIS
4222983 Second Edition 5-3
5
Component Location
See Figures 5-1 and 5-2.
Figure 5-1: Component Location—Right Side
1 Floorboard Assembly 3 Left Cutting Unit 5 Right Lift Arm 7 Front Axle Assembly 9 Center Cutting Unit
2 Traction Pedal 4 Right Reel Lift Actuator 6 Right Cutting Unit 8 Right Fender 10 Center Reel Lift Actuator
TN2744
1
2
8
3
9
4
10
5
6
7
