5-2 4222983 Second Edition
CHASSIS
5
Specifications
Checks and Adjustments
Specifications
Repair Specifications
Specification
Steering Chain Deflection in. (mm) 0.0625–0.250 (1.6–6.4)
[with 2–10 lb (9–45 N)
push at mid-span of chain]
Specification
Front Wheel Hub Castle Nut Torque lb-ft (N·m) 95–115 (10.7–13.0)
Front Axle Assembly—
Mounting Screw Torque
lb-ft (N·m) 65 (88)
Front Axle Assembly—
Axle Housing Face-to-Axle Shaft Seal Outer Face
Measurement
in. (mm) 1.125 (28.6)
Front Axle Assembly—
Bearing Cap Screw Torque
lb-ft (N·m) 35–45 (3.4–5.1)
Front Axle Assembly—
Axle Housing Cover Screw Torque
lb-ft (N·m) 16–25 (1.8–2.7)
