5
4222983 Second Edition 5-1
Chapter 5
Chassis
Specifications ................................................................. 5-2
Checks and Adjustments Specifications ........................................ 5-2
Repair Specifications ....................................................... 5-2
Component Location ........................................................... 5-3
Checks and Adjustments ....................................................... 5-5
Steering Chain Tension Adjustment ........................................... 5-5
Repair ....................................................................... 5-6
Reel Lift Actuators ......................................................... 5-6
Right and Left Lift Arms ..................................................... 5-6
Center Lift Arm ........................................................... 5-9
Steering Yoke ........................................................... 5-11
Steering Chain and Gears .................................................. 5-12
Front Fenders ........................................................... 5-13
Traction Pedal ........................................................... 5-14
Brake Pedal Assembly .................................................... 5-14
Axle Shield and Front Splash Shield .......................................... 5-17
Floorboard .............................................................. 5-18
Front Wheel Hub ......................................................... 5-19
Front Axle Assembly ...................................................... 5-19
