ACCESSORIES AND MISCELLANEOUS REPAIR
4222983 Second Edition 7-3
7
Component Location
See Figure 7-1.
Figure 7-1: Component Location
1 OPS (Operator Protective Structure) 5 Steering Tower 9 Front Wheel (2)
2 Seat and Seat Platform 6 Left Side Cowling 10 Right Side Cowling
3 Armrest Assembly 7 Work Light 11 Rear Wheel
4 Steering Wheel 8 Dome Light 12 Hood
2
9
5
TN2744
1
7
4
6
10
11
12
3
8
