2-10 4222983 Second Edition
SPECIFICATIONS AND GENERAL INFORMATION
2
Chassis
Cutting Units
Check and Adjustment Specifications
Steering Chain Deflection in. (mm) 0.0625–0.250 (1.6–6.4)
[with 2–10 lb (9–45 N)
push at mid-span of chain]
Repair Specifications
Front Wheel Hub Castle Nut Torque lb-ft (N·m) 95–115 (10.7–13.0)
Front Axle Assembly—
Mounting Screw Torque
lb-ft (N·m) 65 (88)
Front Axle Assembly—
Axle Housing Face-to-Axle Shaft Seal Outer Face
Measurement
in. (mm) 1.125 (28.6)
Front Axle Assembly—
Bearing Cap Screw Torque
lb-ft (N·m) 35–45 (3.4–5.1)
Front Axle Assembly—
Axle Housing Cover Screw Torque
lb-ft (N·m) 16–25 (1.8–2.7)
Check and Adjustment Specifications
Bedknife Front Face Height in. (mm) 0.0625 (1.59)
Bedknife Front Face Angle degrees 5
Bedknife Top Face Angle (rear relief) degrees 8–10
Super Tournament Bedknife Top Face Angle
(rear relief)
degrees 5–7
Reel Blade Relief Angle degrees 45
Reel-to-Bedknife Gap in. (mm) 0.001–0.003 (0.025–0.076)
Reel Bearing Pre-Load in. (mm) 0.040 (1.27)
Right/Left Reel Leveling Rod—Rod End-to-Nut Face
Measurement (non-spring side)
in. (mm) 1.625 (41.3)
Center Reel Leveling Rod—Rod End-to-Nut Face
Measurement (non-spring side)
in. (mm) 1.00 (25.4)
Reel Leveling Rod—Rod End-to-Collar Face
Measurement (spring side)
in. (mm) 5.250 (133.4)
Reel Leveling Rod—Rod End-to-Nut Face
Measurement (spring side)
in. (mm) 0.125 (3.2)
Reel Motor Mounting Screw Torque lb-in. (N·m) 75 (8.5)
Bedknife Mounting Screw Torque lb-in. (N·m) 90–120 (10.2–13.6)
