ELECTRICAL
4222983 Second Edition 4-5
4
Component Location
See Figures 4-1 and 4-2.
Figure 4-1: Component Location—Right Side
1 TCU (Traction Control Unit) Fan 4 Steering Input Device 7 Brake Coil
2 TCU (Traction Control Unit) 5 RCU (Reel Control Unit) 8 Traction Pedal Position Sensor
3 OLM (Over Limit Monitor) 6 AC Traction Motor Assembly 9 Resistor Bank Assembly
TN2744,TN2389,TN2418,TN2419
9
5
3
2
1
4
7
6
8
