Jacobsen Eclipse 322 - Electrical System; PDU Components (Later Units)

4-6 4222983 Second Edition
ELECTRICAL
4
Figure 4-2: Component Location—Left Side
1 MCU (Main Control Unit) 3 GCU (Genset Control Unit) 5 LCD (Liquid Crystal Display)
2 PDU (Power Distribution Unit) 4 SCU (Steering Control Unit 6 Ground
TN2746,TN2369,TN2420,TN2417
1
2
6
4
5
3
