Jacobsen Eclipse 322

GENSET AND BATTERY PACK
4222983 Second Edition 3-41
3
Battery Charger
Removal and Installation
See Figure 3-76.
1. Park the mower safely. (See “Park Mower Safely” on
page 1-6.)
2. Raise the hood.
Figure 3-76
NOTE
Label all wires before disconnecting to ensure correct
installation.
TN2708
2
TN2708
1
7
6
3
5
4
