2-4 4222983 Second Edition
SPECIFICATIONS AND GENERAL INFORMATION
2
Component Location
See Figures 2-5 through 2-7.
CAUTION
All Models
Figure 2-5: Component Location—Right Side (Model 62805 Shown)
Become familiar with operator controls, machine
components, and correct operating procedures
before beginning repair procedures.
1 OPS 5 Steering Tower 9 Front Wheel (2)
2 Seat 6 Traction Pedal 10 Center Cutting Unit
3 Steering Wheel 7 Right Reel Leveling Rod 11 Center Reel Leveling Rod
4 Armrest Assembly 8 Right Cutting Unit
TN2745
1
4
2
5
6
3
9
10
7
8
11
