SPECIFICATIONS AND GENERAL INFORMATION
4222983 Second Edition 2-5
2
Figure 2-6: Component Location—Left Side
1 Brake Pedal Assembly 4 Rear Axle Assembly 7 Front Axle Assembly
2 Steering Chain and Gear 5 Starter Battery 8 Left Cutting Unit
3 Rear Wheel 6 Buffer Battery Pack 9 Left Reel Leveling Rod
TN2746
1
7
8
4
9
5
2
3
6
