Jacobsen Eclipse 322 Repair Manual

3-4 4222983 Second Edition
GENSET AND BATTERY PACK
3
Model 62801 (Electric)
Battery Pack 48V (six 8-volt Trojan T890 deep cycle lead
acid batteries) with single point watering
system
Traction Drive System (All Models)
Traction Drive Motor 48-volt, brushless, keyed shaft
Traction Drive Motor Power Rating hp (kW) 3 (2.2) continuous
Repair Specifications
Muffler Mounting Nut Torque
(Diesel Model)
lb-ft (N·m) 7.2–8.3 (9.8–11.3)
Genset Carrier Mounting Screw Torque
(Diesel Model)
lb-ft (N·m) 65.0 (88.0)
Coupling Shaft Mounting Screw Torque
(Diesel Model)
lb-ft (N·m) 13.0 (17.6)
Generator Flange Mounting Screw Torque
(Diesel Model)
lb-ft (N·m) 13.0 (17.6)
Generator Assembly Mounting Screw Torque
(Diesel Model)
lb-ft (N·m) 13.0 (17.6)
Genset Carrier Mounting Screw Torque
(Gas Model)
lb-ft (N·m) 65.0 (88.0)
Mounting Flange Screw Torque
(Gas Model)
lb-ft (N·m) 24.0 (32.5)
Generator Assembly Mounting Screw Torque
(Gas Model)
lb-ft (N·m) 13.0 (17.6)
Isolation Mount Screw Torque
(Gas Model)
lb-ft (N·m) 19.0 (25.5)
Engine Mounting Screw Torque
(Gas Model)
lb-ft (N·m) 19.0 (25.5)
Engine Plate Screw Torque
(Gas Model)
lb-ft (N·m) 19.0 (25.5)
Engine Coupler Screw Torque
(Gas Model)
lb-ft (N·m) 30.0 (40.6)
