3-8 4222983 Second Edition
GENSET AND BATTERY PACK
3
Figure 3-4: Component Location—Left Side
1 48-Volt Connector 4 Buffer Battery Pack 7 Oil Fill Cap
2 Air Cleaner Assembly 5 Starter Battery 8 Fuel Filter
3 12-Volt Connector 6 Oil Dipstick 9 Starter Motor
TN2794,TN2796,TN2797
2
4
5
9
1
3
7
8
6
